Challenger’s CL10V3 model features our exclusive Versymmetric® technology to allow you to service the widest range of vehicles and maximize your bottom line. 3-stage front and 3-stage rear arms with our industry-first directSPOT™ design eliminate the need to shuffle a vehicle back and forth to swing the front arm clear of the tire to reach recommended lift points. Accurate first-try spotting will boost your productivity as well as reduce frustration in your shop.
We also offer the CL10V3 in several configurations to meet your service application needs. A drive-on pad option provides the quickest vehicle spotting for express bays. Our added Quick Cycle™ models can rise in just 27 seconds and lower in only 17 seconds. Quick Cycle™ technology’s increased lift speed will drastically boost your service potential. Adjustable height and width options are also available. In addition, choose between a wide range of accessories to make the CL10V3 the perfect choice for your shop. Expand your service potential with our most versatile, easy-to-operate lift.
- 10,000 lbs. lift capacity
- Versymmetric® offset front arms provide directSPOT™ to vehicle lift points and safely lifts both symmetrically and asymmetrically within the same service bay maximizing service capabilities and revenue potential
- Oversized 5 in. diameter pulley and heavy duty 5/16 in. cable reduces stress on equalization system and increases cable life
- 48 in. elongated carriage design increases lift life
- Three settings for width adjustment, from 11′ 6.5″ to 12′ 6.5″
- Standard model fits 12 foot ceiling height. Additional 2 foot or 3 foot extensions available
- Padded overhead shut off system prevents vehicle damage
- Premium double telescoping screw pads adjust to multiple heights minimizing the need for adapters
- Fully gusseted base plate design increases column rigidity
- Pulley-less jacketed single-point lock release system makes for smoother, easier operation and longer life
- Standard dual integrated rubber door guards help protect vehicle panels from inadvertent damage
- Plated arm restraints and arm pins inhibit rust and provide long-lasting durability
- Premium powder coat finish provides long-lasting durability
- ALI® Certified
| Model Number | CL10AV3 |
|---|---|
| Lifting Capacity | 10,000 lbs. |
| Lift Configuration | Standard |
| Arms | 3-stage front/3-stage rear |
| Rise Height | 74.125” |
| Overall Height | 11' 2" or 11' 8" |
| Overall Height (Cylinder Extended) | 11' 11" |
| 2’ Height Extension Available | Yes |
| 3’ Height Extension Available | Yes |
| Overall Width | 11' 6.5" / 12' .5" / 12' 6.5" |
| Drive-Thru Clearance | 100" / 106" / 112" |
| Floor to Overhead Switch | 10' 8.5" - 11' 2.5" |
| Front Arm Reach | 20” - 42” |
| Rear Arm Reach | 37.625” - 60” |
| Screw Pad Height | 3.875” - 6.125” |
| Inside Columns | 110" / 116" / 122" |
| Motor / Voltage | 2HP, 208v-230v, 60Hz, 1Ph |
| Speed of Rise | 38 s |
| Ceiling Height Required | 12' |
| ALI/ETL Certified | Yes |
| Colors Available | Red, Blue, Black |
