We designed our 30,000 lb. to 60,000 lb. lifts as an economic high capacity lifting solution in a traditional 4-post design. Diamond plated anti-skid runways and ramps provide for positive vehicle traction. The synchro-power system has dual heavy-duty lift cylinders as well as lever controls, which provide variable or synchronous power to the front and/or rear suspension of the lift, making it perfect for lifting large axle vehicles with heavier front or rear ends, including waste trucks and other construction trucks.
- 30,000 lb. to 60,000 lb. capacity 4-post
- 310” to 430” max wheelbase
- 32” wide runways aid for drive-on confidence
- 10 lock positions provide maximum head room for working underneath vehicles (40K-60K)
- Single-point air actuated lock release allows technicians to disengage column locks simultaneously
- Diamond-plate approach ramps for positive vehicle traction
- Optional 15,000 lb. – 35,000 lb. rolling jacks provide complete optimization for your heavy-duty servicing needs
- Available with black columns only
Model Number | 44030E |
---|---|
Lifting Capacity | 30,000 lbs. |
Max Wheelbase | 290" |
Rise Height | 68" |
Overall Length | 29' 7.5" |
Overall Width | 12' 5.5" |
Inside Columns | 132.5" |
Between Columns | 293.75" |
Height Overall | 92" |
Height of Runways | 9" |
Width of Runways | 24" |
Width Between Runways | 54" - 75" |
Width Between Runways with jacks | NA |
Motor / Voltage | 3HP, 208-230v Single Phase |
Amps | 30 |
Speed of Rise | 105 s |
Colors Available | Black |
